pMLTE-4GL-ALO | Accessories | Downloads
pMLTE-4GL Banner

Wireless MIMO (2X2) OEM Digital Data Link with LTE

Verizon Airborne LTE Operation (ALO) Certified for Drone Operations!

The all new pMLTE-4GL Series combines our high powered Digital Data Link and a robust LTE Connection into a single compact OEM package. The Digital Data Link features 2x2 MIMO, Maximal Ratio Combining (MRC), Maximal Likelihood (ML) decoding and Low-Density Parity Check (LDPC) to achieve robust RF performance. Available in 2.4 , 2.3 or 2.5 GHz models. The LTE connection provides globally supported LTE Bands with 3G/HSPA Fallback and delivers up to 150 Mbps. The pMLTE features Dual Ethernet, USB, Dual RS232 Serial/Console and GPS!


  • Digital Data Link > 25 Mbps!
  • Robust 2X2 MIMO
  • Adjustable Total Output Power (1W)
  • Maximal Ratio Combining (MRC), Maximal Likelihood (ML) decoding
  • Low-Density Parity Check (LDPC)
  • 4G/LTE w/Global Band Support
  • 150Mbps(DL)/50 Mpbs(UL) LTE
  • Compact & Lightweight
  • Point-to-Point, Point-to-Multipoint
  • Master, Remote, Relay, Mesh Modes
  • Serial & USB Ports
  • Dual Ethernet Ports (LAN/WAN)
  • Port Forwarding, ACL, Firewall
  • Extended Temp (-40°C to +85°C)
  • 128-bit AES Encryption
  • Configurable via console, telnet, webUI
  • Local/Remote firmware upgrades


  • Ethernet Wireless Extension
  • Wireless Telemetry
  • Wireless Video
  • Wireless Control Systems


  • FCC
  • Industry Canada
  • Verizon ALO Certified
    (Airborne LTE Operation)
  • Carrier Specific Approvals:

pMLTE-4GL Images


pMLTE Order Options

Model Frequency/Notes
pMLTE-4GL-ALO 2.402-2.478 GHz
Verizon ALO Certified
pMLTE-4GL-2450 2.402-2.478 GHz
pMTLE-4GL-2350 2.304-2.390 GHz
pMTLE-4GL-2550 2.500-2.570 GHz
